AS-11 Video Specifications


Extreme Reach provides multiple solutions for uploading creative assets to your account. Whether you choose to upload assets via our Media Uploader Application or through the ER platform, all files must meet the specifications in this document before they can be accepted.

Video and Audio Specifications

  Preferred   Alternative
Format MXF OP1a QuickTime QuickTime
Video Codec XDCAM HD 422 ProRes 422 HQ ProRes 422 HQ
GOP Long GOP Default Default
Frame Size 1920 x 1080 1920 x 1080 1920 x 1080
Frame Rate 25.00 25.00 23.98
Scan Type Progressive Progressive Progressive
Aspect Ratio 16:9 16:9 16:9
Pixel Aspect Ratio Square Pixels (1.0) Square Pixels (1.0) Square Pixels (1.0)
Bit Rate 50 Mbps / CBR Default Default
Chroma 4:2:2 4:2:2 4:2:2
Audio Codec PCM PCM PCM
Bit Depth 24 bit 24 bit 24 bit
Sample Rate 48 kHz 48 kHz 48 kHz
Channels Stereo Stereo Stereo


The alternative format will undergo an automatic standards conversion to 25.00 fps. Because of this, we do not recommend uploading this format for any video with heavy motion or overlay graphics in panning scenes, as the conversion may introduce artifacts when up-converting the frames.


Clock/Slate Information

A valid clock/slate is not required. Only the commercial is required.

Slates for AS-11 uploads are system generated from metadata and analysis of the source media. This process ensures that all information required is included. Original slates are not passed through.
  • No pre or post-roll is required, such as black, hold, or freeze.
  • Assets must be frame accurate, and they must start and end with an active image.
  • Edits utilizing fades must ensure the first and last frames have images and are not in true black.

Duration Example Timecode
30" 00:00:00:00 - 00:00:29:24
Duration of commercial
(Duration should be an exact number of seconds)
(6 Frames)
(Must be shorter than the video to allow for required silence)
(6 Frames)
Duration of audio


Ad Code Formats


UK (Clock): AAA/BBBB123/456

AU (Key): AAABBB123456

FR (Pub): FR_TRAF_ADVR_BRND_0001_030_F

Video Levels

All video signals should comply with ITU-R BT.709-5 and video signals should not exceed the specified limits.

Video levels should not exceed 700mV, or fall below 0mv

Out of gamut tolerance - EBU recommendation Rec.103-2000 will allow a small tolerance, assuming that no more than 1% of the active picture is in error.

Luminance (Y) -1% and 103%
(ie between -7mV and 721mV)

RGB video levels -5% and 105%
(ie between -35mV and 735mV)


EBU R.128-2014

  • Integrated Loudness Program : -23 LUFS
  • Target Level Tolerance : +/- 0.5 LU
  • Maximum True Peak : -1dBTP
  • Maximum Momentary : No Limitations
  • Maximum Short Term Momentary (3 Sec) : -18 LUFS
  • Loudness Range : No Limitations

Although the maximum true peak is -1dBTP, it is recommended by the broadcasters that the true peak should not exceed -3dBTP.

IMPORTANT Notes Regarding Audio Silence:

  • UK and ROI Specifications require the first 6 frames and the last 6 frames of the audio to be mute. Trace audio within the first or last 6 frames is a QC fail.
  • AU Specifications require the first 12 frames and the last 12 frames of the audio to be mute. Trace audio within the first or last 12 frames is a QC fail.
  • Digital silence should achieve a recommended level not exceeding -70dBFS.

Audio Dialogue

The best practice for a globally acceptable audio mix regarding dialogue is to start and end spoken word 12 frames into and out of content. Dialogue may get cut off if someone talks during an asset's initial beginning or end. In this instance, the post house will require a new audio mix.

Closed Captioning/Subtitling

World System Teletext (or WST ) is the standard for encoding and displaying Teletext information, used as the standard for Teletext throughout Europe today. It was adopted into the international standard ITU-R BT.653, for HD OP-47 is the accepted format.
